Spec:
Flange Size: T4
Wastegate Type: GTII φ60
Kit Includes: HKS cast Exhaust Manifold, HKS Special Wastegate(φ60), Wastegate return pipe, oil inlet and outlet pipe, flange, gasket, bolts and nuts etc.
For Supra, JZA80, 2JZ-GTE engine, MY 05/1993 - 08/2002
Remarks:
- Doesn't include turbocharger assembly.
- This kit may require modification or additional fabrication of parts such as intake pipes.
HKS SPECIAL SET UP KIT Concept and Features:
HKS provides easy solution of single turbine set up kit for GTIII-4R turbo.
Contents:
GTIII-RS Turbocharger Assy with an actuator.
Oil & Water Piping Parts
Air Cleaner, Suction Pipe
Front-mounted Intercooler, Piping
Exhaust Manifold,
For 11001-AT005, Extension with CAT
Insulator Cover, Insulator Sheet
Gaskets, Brackets, Bolts, etc.
For 86, ZN6, FA20 engine, 04/2012 - 07/2016
For MT, Extension with CAT. Compatibility with the late model is confirmed only with JDM model.
Click here to check the performance data in HKS page
Note:
This kit can be used with HKS S-TYPE OIL COOLER KIT.
* OIL COOLER KIT is NOT included in this kit.
* This is an image of a prototype and may differ from the actual product.
* Reinforced fuel parts such as injectors are required.
* Pressure sensor is required separately.
* Vehicle modification is required in order to install this kit
* Engine management parts are not included in this kit.
* Resetting is required.
Features:
HKS has released a long-waited Bolt-on Turbo Kit with GTIII-RS turbine for 86/BRZ.
GTIII-RS turbine that is the best match with 2L engine, special designed turbo housing, and other special parts are made by HKS special turbo technology.
This kit is available from a stock to tuned engine.
The engine output will reach 450ps when this kit is installed to a tuned engine.
* Another kit including the extension with CAT is additionally available.
Boost Pressure: 78.5-88.3kPa (0.8-0.9kgf/cm2)
FCD: Type H
For SILVIA, S14 S15, Engine SR20DET, MY10/1993-08/2002
Click here to check HKS page
Main Features
(1) You can have boost up even before the EVC installation.
HKS electric boost controller "EVC" control the engine boost with the function of correction map. But this enhanced actuator can be installed even before the EVC setup and enjoy the boost up. Of course, you can use it with EVC, too.
(2) Less effect on control of stock and has stable boost up.
10kPa(0.1kg/cm2) boost up capacity design, compare to the stock. This level of boost up can be controlled by stock ECU.
(3) The boost up feel of half throttle or high rotation speed range.
You cannot have boost up or stability at high speed rotation range with the normal actuator but with the HKS' know-how produced original actuator design can have them.
(4) Adopted turnbuckle specification rod end
Can adjust the supercharging pressure without taking off the rod end from turbo crankarms because of the turnbuckle specification rod end.
(5) Cool looks in engine room
For aluminum machined actuator case of purple alumite looks great. The awesome looking product, right next your turbo.
Boost Pressure: 76.3-88.3kPa (0.8-0.9kgf/cm2)
For IMPREZA, GRB, Engine EJ207, MY10/2007-08/2014
Check HKS page for details
Remarks: Boost control by EVC required.
Features:
By just installing the kit to normal turbine, you can get more power, and it's very cost-ffective.
Easy power up
You can get more power and higher boost just by changing the normal turbine installed actuator.
Cost-effective
You can use existing turbine for the first step of the tune-up.
Adjustable boost pressure
You can adjust boost pressure for your needs with rod that is installed to the actuator by expansion and contraction.
Precautions:
When you just want to increase the supercharging pressure, there is risk of damaging the engine by fuel insufficiency. So for the high supercharging pressure setting, you should use fuel cut defencer(FCD) or fuel control system (F-CON).
Remarks - Do not use with Racing Suction (Reloaded).
For ARISTO, JZS161, Engine 2JZ-GTE, MY 08/1997 - 07/2005
Features:
- With Super SQV Kit, blow-off air will return to suction like stock air bypass valve to be street legal.
- Although blow off sound will be reduced, more sound will come out from air cleaner.
