JDM specialist Japanparts.com

Increased Volume Rear Differential Cover released for the Subaru Impreza R180 series carrier housing. Increased capacity is ideal for use in competitive motorsports or overall aggressive driving to ensure LSD and final drive longevity. Protect your investment! The increased oil volume promotes heat build up and dissipation where the fluid keeps the moving components well lubricated at all times. Two types of billet aluminum anodized covers are available, blue and silver. Complies with GC8, GDB/GGB, GRB/GVB Imprezas that are equipped with R180 rear differential carriers. (Will not fit R160) -FEATURES- 1.Recommended for use on the circuit or overall aggressive driving. 400cc more oil capacity than factory. - Factory: 0.8-0.9L (+-0.05L) oil capacity - Cusco: 1.2-1.3L (+-0.05) oil capacity 2.Heat sink fins promote enhanced cooling features 3.Billet anodized aluminum highly durable 4.Pre-tapped M16ｘP1.5 holes for external oil coolers Notes: Requires Subaru OEM components below - Air Breather Cap 38354AA020 ×1 - Gasket (Differential Carrier) 38353AA050 ×1 - Gasket (T-type H3 & H4 oil temp sensor type only) 803920050 x 2 Parts number: Blue: 692 008 AL / Silver 692 008 AS

A set of 20pcs. Please choose the size from (#00B-738-1520TI) M12 x P1.5 or (#00B-738-12520TI) M12 x P1.25

For IMPREZA WRX STI A-LINE, GRF MY: 02/2009 - 08/2014, GVF MY: 07/2010 - 08/2014  Engine：EJ25 TURBO / Transmission：5AT / Attachment position：R  Standard diff type: Viscous coupling   * VDC won't work correctly. EXIGA YA5 MY: 06/2008 -  Engine：EJ20 Turbo / Transmission：5AT / Attachment position：R  Standard diff type: OPEN type LEGACY BP5 BL5 MY: 05/2003 - 05/2009  Engine：EJ20 TURBO / Transmission：5AT / Attachment position：R  Standard diff type: Viscous coupling  * VDC won't work correctly. LEGACY OUTBACK BPE MY: 10/2003 - 05/2009  Engine：EZ30 / Transmission：5AT / Attachment position：R  Standard diff type: Viscous coupling LEGACY BR9 BM9 MY: 05/2009 - 10/2014  Engine：EJ25 TURBO / Transmission：5AT / Attachment position：R  Standard diff type: Open type LEGACY OUTBACK BRF MY: 05/2009 - 10/2014  Engine：EZ36 / Transmission：5AT / Attachment position：R  Standard diff type: Open type FORESTER SH9 MY: 10/2010 - 11/2012  Engine：EJ25 TURBO / Transmission：5AT / Attachment position：R  Standard diff type: Open type Available type and the initial setting - 1&2WAY initial setting 1WAY (LSD 684 F) or 2WAY (LSD 684 F2) - 1.5&2WAY initial setting 1.5WAY (LSD 684 L15) or 2WAY(LSD 684 L2) Link: CUSCO LSD type-RS features (html), CUSCO LSD GUIDE (pdf)

A set of 2pc. With rubber boot.

For WRX S4 VAG MY: 08/2014 -   Engine：FA20 TURBO / Transmission：AT / Attachment position：R   Standard diff type: Open type diff IMPREZA SPORTS WAGON GF8 MY: 09/1998 - 08/2000   Engine：EJ20 TURBO / Transmission：MT AT / Attachment position：R   Standard diff type: SURETRAC IMPREZA SPORT WAGON GGA Applied A-G MY: 08/2000 - 06/2007   Engine：EJ20 TURBO / Transmission：MT / Attachment position：R   Standard diff type: SURETRAC FORESTER SF5 MY: 08/1998 - 02/2002   Engine：EJ20 TURBO / Transmission：MT AT / Attachment position：R   Standard diff type: VISCOUS / Remarks: VDC will not work correctly. FORESTER SF9 MY: 09/1998 - 02/2002   Engine：EJ25 / Transmission：MT AT1 / Attachment position：R   Standard diff type: VISCOUS / Remarks: Not apply for the car with the suretrac diff. FORESTER SG5 MY: 02/2002 - 12/2007   Engine：EJ20 TURBO, EJ20 / Transmission：MT AT / Attachment position：R   Standard diff type: VISCOUS FORESTER SH5 MY: 12/2007 - 11/2012   Engine：EJ20 TURBO / Transmission：5MT 4AT / Attachment position：R   Standard diff type: Open type diff FORESTER SH9 MY: 10/2010 - 11/2012   Engine：EJ25 TURBO / Transmission：4AT 5MT / Attachment position：R   Standard diff type: Open type diff LEVORG VMG MY: 06/2014 -   Engine：FA20 TURBO / Transmission：CVT / Attachment position：R   Standard diff type: Open type diff LEGACY TOURING WAGON B4 BP5 BL5 MY: 05/2003 - 05/2009   Engine：EJ20 TURBO / Transmission：5MT / Attachment position：R   Standard diff type: VISCOUS / Remarks: VDC will not work correctly. LEGACY TOURING WAGON B4 BR9 BM9 MY: 05/2009 - 10/2014   Engine：EJ25 TURBO / Transmission：6MT / Attachment position：R   Standard diff type: Open diff LEGACY TOURING WAGON B4 BRG BMG MY: 05/2012 - 10/2014   Engine：FA20 TURBO / Transmission：CVT / Attachment position：R   Standard diff type: Open diff LEGACY OUTBACK BR9 MY: 05/2009 - 04/2012   Engine：EJ25 / Transmission：CVT / Attachment position：R   Standard diff type: Open diff LEGACY OUTBACK BRM MY: 05/2012 - 10/2014   Engine：FB25 / Transmission：CVT / Attachment position：R   Standard diff type: Open diff LEGACY OUTBACK BS9 MY: 10/2014 -   Engine：FB25 / Transmission：CVT / Attachment position：R   Standard diff type: Open diff Available type and the initial setting - 1&2WAY initial setting 1WAY (LSD 183 A) or 2WAY (LSD 183 A2) - 1.5&2WAY initial setting 1.5WAY (LSD 183 K15) or 2WAY(LSD 185 K2) Link: CUSCO LSD type-MZ features (html), CUSCO LSD GUIDE (pdf)

For SKYLINE GT-R BNR32 MY:08/1989 - 12/1994  Engine：RB26DETT / Transmission：MT / Attachment position：F   Standard diff type: Open type SKYLINE GT-R BCNR33 MY:01/1995 - 11/1999  Engine：RB26DETT / Transmission：MT / Attachment position：F   Standard diff type: Mechanical type SKYLINE GT-R BNR34 MY:01/1999 - 08/2002  Engine：RB26DETT / Transmission：MT / Attachment position：F   Standard diff type: Mechanical type Available type and the initial setting - 1WAY initial setting 1WAY (LSD 137 A) - 1&1.5WAY initial setting 1WAY (LSD 137 B) or 1.5WAY(LSD 137 B15) Link: CUSCO LSD type-MZ features (html), CUSCO LSD GUIDE (pdf)

For SKYLINE GT-R BNR32 MY:01/1993 - 12/1994  Engine：RB26DETT / Transmission：MT / Attachment position：R   Standard diff type: Mechanical type SKYLINE GT-R BCNR33 MY:01/1995 - 11/1999  Engine：RB26DETT / Transmission：MT / Attachment position：R   Standard diff type: Mechanical type SKYLINE GT-R BNR34 MY:01/1999 - 08/2002  Engine：RB26DETT / Transmission：MT / Attachment position：R   Standard diff type: Mechanical type Available type and the initial setting - 1&2WAY initial setting 1WAY (LSD 169 E) or 2WAY(LSD 169 E2) - 1.5&2WAY initial setting 1.5WAY (LSD 169 K15) or 2WAY(LSD 169 K2) Link: CUSCO LSD type-MZ features (html), CUSCO LSD GUIDE (pdf)

For SKYLINE GT-R BNR32 MY:08/1989 - 12/1994  Engine：RB26DETT / Transmission：MT / Attachment position：F   Standard diff type: Open type SKYLINE GT-R BCNR33 MY:01/1995 - 11/1999  Engine：RB26DETT / Transmission：MT / Attachment position：F   Standard diff type: Mechanical type SKYLINE GT-R BNR34 MY:01/1999 - 08/2002  Engine：RB26DETT / Transmission：MT / Attachment position：F   Standard diff type: Mechanical type Available type and the initial setting - 1WAY initial setting 1WAY (LSD 137 F) - 1&1.5WAY initial setting 1WAY (LSD 137 C) or 1.5WAY(LSD 137 C15) Link: CUSCO LSD type-RS features (html), CUSCO LSD GUIDE (pdf)

For SKYLINE GT-R BNR32 MY:01/1993 - 12/1994  Engine：RB26DETT / Transmission：MT / Attachment position：R   Standard diff type: Mechanical type SKYLINE GT-R BCNR33 MY:01/1995 - 11/1999  Engine：RB26DETT / Transmission：MT / Attachment position：R   Standard diff type: Mechanical type SKYLINE GT-R BNR34 MY:01/1999 - 08/2002  Engine：RB26DETT / Transmission：MT / Attachment position：R   Standard diff type: Mechanical type Available type and the initial setting - 1&2WAY initial setting 1WAY (LSD 169 F) or 2WAY(LSD 169 F2) - 1.5&2WAY initial setting 1.5WAY (LSD 169 L15) or 2WAY(LSD 169 L2) 1WAY initial setting 1WAY (LSD 169 FD) Link: CUSCO LSD type-RS features (html), CUSCO LSD GUIDE (pdf)

For BNR34 RB26DETT M/T after 1999/01. Standard Diff Type has to be LSD. Please choose it for front (35 degree with 1way) or for rear (55 degree with 1 way). Can NOT equip Active LSD equip model. Parts number: LSD 137 S Front LSD 169 S Rear
