Home > result > 233-101-022

  • TEIN
  • STREET BASIS Z (GSTB4-81AS2)
  • (Japanparts No :

    233-101-022

    )

 Click on the image above to enlarge

  • 101,200 JPY  (
    Convert

    Home Currency Selection

    Select your home currency from the list below.
    Then click on "Set Home Currency" button to set your home currency.

    )
  • You save 21,252JPY
  • 79,948 JPY  (
    Convert

    Home Currency Selection

    Select your home currency from the list below.
    Then click on "Set Home Currency" button to set your home currency.

    )
  • Quantity :

add to Wish List

item is added to Wish List

already added to Wish List

Member page Login

Please input your Email address and password.

Email address
Password
Estimated delivery time by EMS/Courier
10-15 days
  • Car category
  • Toyota

    • Alphard H3#

  • Compatible with:
  • GGH30W, Grade- SA, SA C PACKAGE, GF, EXECUTIVE LOUNGE, 3500cc, FF, MY 01/2015 -
  • Product
    Details
  • Ask about
    Product
  • Ratings and
    Review

Suspension & Steering

 >

Coilovers

Product Information

Compatibility: Compatible model.
SPRINGS: included
EDFC compatibility: N/A.
Damping force adjustment: Front-N/A / Rear- N/A
Full-length ride-height adjustable: Front- N/A / Rear- N/A
Upper mount: Front- UPPER MOUNTS not included.(Please use OE.) / Rear- UPPER MOUNTS not included.(Please use OE.)
Base ride height drop(mm): Front: -45 / Rear: -45
Ride height adjustable range(mm): Front: MAX LOW - HI: -84 to -32, RECOMMENDED LOW - HI: -55 to -35 / Rear: MAX LOW - HI: -75 to -38, RECOMMENDED LOW - HI: -55 to -40
Spring: Front: RATE(N/mm / Kgf/mm): 39.2/4.0, FREE LENGTH(mm)/I.D.(mm): 275/ / Rear: RATE(N/mm / Kgf/mm): 88.6/9.0, FREE LENGTH(mm)/I.D.(mm): 208/
[ NOTE ] NOT COMPATIBLE WITH VEHICLE EQUIPPED WITH SIDE LIFT-UP SEAT.
Check TEIN page for details

For ALPHARD, GGH30W, Grade- SA, SA C PACKAGE, GF, EXECUTIVE LOUNGE, Engine- 3500cc, Drive train- FF, MY 01/2015 -

Features:
Incredibly low price - Shock absorber for street use with an astonishing price tag.
Sealed Structure
Thread-Type ride height adjustment
Twin-tube system
Uses OE mounts
High durable & reliability- TEIN-Green Powder Coating, Special Surface Treatment "ZT Coating"

Note:
This item may require an extra shipping charge depending on the destination country. If it does, we will contact you by email within 3 business days after the order is placed and tell you how much extra it costs for shipping. You can ask us to cancel the order if you would not like to pay the difference. We will proceed with the order once we receive the extra payment from you.
