SPRINGS: included
EDFC compatibility: Extention Kit required. Motor install location is not confirmed. If you would like to buy, leave the message in the comment field in the process of ordering. Pay us later by PayPal.
Damping force adjustment: Front- available / Rear- available
Full-length ride-height adjustable: Front- N/A / Rear- N/A
Upper mount: Front- UPPER MOUNTS not included.(Please use OE.) / Rear- UPPER MOUNTS not included.(Please use OE.)
Base ride height drop(mm): Front: -45 / Rear: -30
Ride height adjustable range(mm): Front: MAX LOW - HI: -78 to -34, RECOMMENDED LOW - HI: -55 to -35 / Rear: MAX LOW - HI: -62 to -15, RECOMMENDED LOW - HI: -40 to -20
Spring: Front: RATE(N/mm / Kgf/mm): 39.2/4.0, FREE LENGTH(mm)/I.D.(mm): 225/ / Rear: RATE(N/mm / Kgf/mm): 39.2/4.0, FREE LENGTH(mm)/I.D.(mm): 210/
[ NOTE ] DUE TO INDIVIDUAL DIFFERENCES, THE REQUIRED 90MM ROAD CLEARANCE MIGHT NOT BE SECURED AT THE RECOMMENDED RIDE HEIGHT POSITION. WHEN USING THE PRODUCT, PLEASE ADJUST THE RIDE HEIGHT ACCORDINGLY TO SECURE THE 90MM MINIMUM ROAD CLEARANCE. SPRING SEAT POSITION: FT/RR=+13/+5MM, COMPARED TO E12.
Check TEIN page for details

For NOTE E-POWER NISMO, HE12, Grade- E-POWER NISMO, Engine- 1200cc, Drive train- FF, MY 12/2016 -

Features:
Incredibly low price - Shock absorber for street use with an astonishing price tag.
Sealed Structure
Thread-Type ride height adjustment
Twin-tube system
Uses OE mounts
High durable & reliability- TEIN-Green Powder Coating, Special Surface Treatment "ZT Coating"
Damping force adjustable

Note:
This item may require an extra shipping charge depending on the destination country. If it does, we will contact you by email within 3 business days after the order is placed and tell you how much extra it costs for shipping. You can ask us to cancel the order if you would not like to pay the difference. We will proceed with the order once we receive the extra payment from you.
